High Throughput Burn-in Chamber

Burn-in Temperature Chamber

A temperature chamber capable of long dwell times and wide temperature ranges (-55 to 500°C) for Electro/Stress Migration, Time Dependent Dielectric Breakdown, and Hot Carrier / Vt Stability Tests.

These chambers can be designed with card cages, card-slots, and access doors to simplify connecting DUT boards and driver boards with ATE test setups. Equipped with a programmable, touch-screen controller, the chambers deliver 1.0°C accuracy.

Benefits:

  • High capacity testing, up to 60 load boards or hundreds of DUTs
  • Change DUTs without removing driver boards and test connections
  • Connect driver boards easily with slotted pull-off door
  • Reduce condensation with dry air purge
  • Maintain uniform air flow regardless of how many boards in chamber
  • Communicate remotely - IEEE, RS232, Ethernet

What are your burn-in requirements?
See more burn-in chambers and chamber configurations.
